Tabor LS6081D Signal Generator Module

Tabor / Signal Generator Module / LS6081D

6GHz RF Analog Signal Generator Module

The Lucid family of signal generators is a small footprint modular microwave signal generator that is available in multiple form factors, including Desktop, benchtop, rackmount, and portable. It has been designed to provide signal fidelity, with a frequency range up to 12GHz.

● 3GHz, 6GHz, 12GHz RF Analog Signal Generator
● Fast switching speed of <100μs
● AM, FM, PM, Sweep & Pulse Modulation
● Phase Noise of -138dBc/Hz @1GHz and 10@kHz offset
● Compact modular platform

OPTION

Option	Description
MOD	Modulation Package (AM, FM, PM)
PLS	Pulse Gennerator
PAT	Pattern Generator
LP	Low Power option to -90 dBm
FS	Fast Switching option 100us
EMU	Emulator Pack includes emulators for Keysight, R&S, Anapico & Holzworth
STN	Lucid desktop holder. Designed to hold the module upright.
WE	1 year warranty extension (standard warranty 3 years)

Note: Options and Accessories must be specified at the time of your purchase.
