Gigatronics / Synthesized Sweeper / 12508A/23/24/26

Minimum Frequency                   10 MHz
Maximum Frequency                    8 GHz
Frequency Resolution               0.1 Hz
Minimum Output Power              -120 dBm
Maximum Output Power                15 dBm
Output Accuracy                    0.5 dB
Output Impedance                    50 Ohm
Minimum Single-Side-Band Noise    -135 dBc/Hz
Maximum Single-Side-Band Noise     -65 dBc/Hz
Harmonics (noise)                  -65 dBc
Non-harmonics (noise)              -60 dBc
Modulation                          AM,FM,Phase,Pulse
Sweep Modes                         Linear,Log

OPTION
