TOA SM-8205 Megaohm Meter

TOA / Megaohm Meter / SM-8205

Measuring  voltage & range
50V 0.25x10x6 ~1x10x12Ω
100V 0.5x10x6 ~ 2x10x12Ω
250V 1.25x10x6 ~ 5x10x12Ω
500V 2.5x10x6 ~ 1x10x13Ω
1,000V 5x10x6 ~ 2x10x13Ω

accuracy of measuring voltage
±3% of each measuring voltage

accruacy of measurement
±10%(5~50 Scale of the 1,000V)

power requirement
100/120/220/240v 50,60Hz Other voltage is available upon request.

estemal dimensions
appros. 280(w) x 190(h) x 222(d)mm

weight approx.
5kgs.

OPTION
